Busbar rwb thaiv tsev xim
Khoom Description
Busbar Rwb thaiv tsev xim siv siab -purity T2 tooj liab ua cov khoom siv. Tom qab ntau yam pretreatments, suav nrog degreasing, xeb tshem tawm, thiab phosphating, qhov saum npoo yog coated nrog epoxy, polyester, los yog hybrid hmoov rwb thaiv tsev txheej siv cov txheej txheem electrostatic hmoov txheej. Cov txheej txheem no tsis yog tsuas yog txhim kho cov rwb thaiv tsev kev ua tau zoo thiab kev tiv thaiv corrosion ntawm cov tooj liab busbars tab sis kuj zam cov kev phom sij zais, xws li npuas, tev, thiab kev sib tsoo hauv zos, tshwm sim los ntawm cov tsoos cua sov- ntsws tubing los yog insulating daim kab xev.
Cov qauv no tso cai rau Busbar Bonded Powder Coatings kom tswj tau qhov tsis tshua muaj hluav taws xob tsis zoo thaum muab kev tiv thaiv hluav taws xob zoo, ua rau nws yog qhov kev xaiv zoo tshaj plaws rau siab - ntom, modular wiring nyob rau hauv niaj hnub fais fab electronics systems.
Khoom nta thiab Technical Highlights
High rwb thaiv tsev Performance
Kev siv siab -voltage- cov ntaub ntawv tiv thaiv hmoov, txheej txheej rwb thaiv tsev yog ib yam thiab ntom, muaj peev xwm tiv taus lub zog dielectric ntau tshaj qhov yuav tsum tau muaj voltage.
Qhov saum npoo yog tsis muaj pinholes, npuas, thiab tawg, kom ntseeg tau ntev - lub sij hawm ruaj khov rwb thaiv tsev.
01
Zoo heev Adhesion thiab Abrasion Resistance
Lub electrostatic tsuag txheej adheres rau tooj liab substrate, tiv taus tev lossis delamination.
Epoxy Bus Bar Txheej muaj qhov cuam tshuam zoo thiab khawb tsis kam, hloov mus rau ntau yam kev ua haujlwm thaum lub sijhawm teeb tsa, kev thauj mus los, thiab kev ua haujlwm txuas ntxiv.
02
Ua kom sov thiab noo noo tsis kam
Cov hmoov txheej tuaj yeem tiv taus kev ua haujlwm kub txog 120℃yam tsis muaj xim lossis tawg.
Nws yog noo noo- pov thawj thiab corrosion{1}} tiv taus, tiv thaiv oxidation tsis ua hauj lwm ntawm tooj liab Insulated Txheej Tinned Khoom Copper Busbar Connector nyob rau hauv high humidity los yog ntsev tsuag ib puag ncig.
03
Environmentally Friendly Process, Safe thiab Pollution -Dawb
Tag nrho cov txheej txheem siv cov kuab tshuaj-dawb electrostatic hmoov txheej txheej txheem, tsis muaj VOC emissions, ua raws li RoHS thiab REACH ib puag ncig cov qauv.
Cov hmoov yog recyclable, ua rau ntsuab manufacturing ntau zog-ntau.
04
Precisely Controllable Txheej Thickness
Cov txheej txheej yog feem ntau tswj ntawm 0.2 thiab 0.4 hli, kom ntseeg tau tias muaj hluav taws xob txaus tsis cuam tshuam rau kev sib dhos.
Txawv thicknesses, xim, thiab cov ntaub ntawv formulations yuav customized raws li tus neeg yuav tsum tau qhov project.
05
Cov txiaj ntsig ntawm daim ntawv thov: Ua haujlwm siab - Kev ntseeg tau ua haujlwm thoob plaws ntau qhov kev lag luam
| Tshiab Zog Cia Systems |
Haum rau cov roj teeb cluster busbars, DC busbars, thiab module txuas terminals; Muab kev nyab xeeb rwb thaiv tsev thiab thermal stability, ua kom muaj kev ua haujlwm zoo. |
| Hluav taws xob tsheb thiab cov khoom siv them nqi |
Dav siv nyob rau hauv siab -voltage fais fab faib units, DC / DC converters, thiab them pawg busbar systems; Tiv thaiv arc tawg, txhim kho kev nyab xeeb thiab kev ua neej nyob. |
| Photovoltaic thiab Cua Fais Fab Inverters |
Haum rau siab -voltage, siab - tam sim no fais fab kis tau tus mob busbars; Optimizes tshav kub dissipation thiab hluav taws xob rwb thaiv tsev kev ua tau zoo, kev txhim kho zog conversion efficiency. |
| Industrial Distribution Cabinets thiab Low-Voltage Control Systems |
tuaj yeem hloov cov cua sov ib txwm-shrink tubing insulated busbars, muab qhov zoo nkauj thiab yooj yim installation; Haum rau PLC tswj cov txee, cov khoom siv zaus hloov pauv, cov khoom siv hluav taws xob, thiab lwm yam. |
Tsim kom muaj txiaj ntsig: Kev ua kom zoo dua qub pib los ntawm cov ntsiab lus
Modular thiab Customized Design
Kev ua tiav yog muaj raws li cov neeg siv khoom kos duab, txhawb kev tsim xws li khoov, xuas nrig ntaus, ntsia liaj qhov rooj, thiab ua ntej - cov txheej txheem rwb thaiv tsev.
01
Daim Ntawv Pov Thawj Tag Nrho ntawm Ntug thiab Cov Khaub Ncaws
Multi-kev taw qhia electrostatic txau yog siv ntawm cov npoo thiab cov ces kaum kom tsis muaj cov kaum tuag hauv kev tiv thaiv kev tiv thaiv.
02
Xim Coding thiab Kev Tiv Thaiv Kev Nyab Xeeb
Cov xim sib txawv ntawm cov xim rwb thaiv tsev yog muab los qhia qhov txawv ntawm cov theem hluav taws xob, polarity, thiab kev ua haujlwm.
Ua kom yooj yim ntawm - kev txheeb xyuas qhov chaw thiab kev saib xyuas, thiab txhim kho qib kev nyab xeeb ntawm cov hluav taws xob.
03
Optional Thickened thiab Localized Protection Design
Rau yooj yim hnav los yog siab - qhov kub thiab txias, customized localized thickened coatings los yog siab - kub resistant hmoov txheej tov muaj.
Busbar Txheej Powder Ua raws li qhov yuav tsum tau ua ntawm ntau- xwm txheej, siab - kev siv zog.
04
Vim li cas thiaj siv rwb thaiv tsev xim hloov cov cua sov Shrink Tubes?
| Cov khoom sib piv | Rwb thaiv tsev xim | Thaum tshav kub kub Shrink Tube |
| Thickness Tswj | meej | Nruab nrab |
| Complex Geometry Kev Pabcuam | Zoo heev | txwv |
| Ntug tiv thaiv | Zoo dua | Nruab nrab |
| Qhov chaw ua ke | Me me | Loj dua |
| Automated Ntau Lawm | Yog lawm | txwv |
| Kev sib xyaw ua ke saum npoo | Direct Bonding | Lub tes tsho sab nraud |
