Beryllium Sheet Stamping Terminals Parts
Khoom Description
Tsis zoo li ib daim ntawv pov thawj, qhov no Beryllium Sheet Stamping Terminals Parts yog ib qho kev sib koom ua ke ntau yam. Nws peb - txheej txheej txheej ua haujlwm tshwj xeeb thaum ib txhij ua tiav qhov kawg synchronization hauv qhov ntsuas qhov ntsuas:
Beryllium Copper Sheet: Ua haujlwm raws li ob qho tib si lub zog thiab cov khoom thauj tam sim no, muab cov elasticity zoo rov qab thiab kev coj ua.
Silver Alloy Contacts: Nyob rau ntawm qhov kawg ntawm daim ntawv, ua lub cev sib cuam tshuam rau kev hloov tam sim no thiab tiv thaiv kev hloov pauv hloov pauv.
Mos Sib Nqus Armature: Riveted mus rau nruab nrab lossis hauv paus ntawm daim ntawv, tswj los ntawm electromagnetic coil, tsav daim ntawv kom ua tiav qhov kev hloov pauv.
Cov yam ntxwv tshwj xeeb: daws peb qhov mob loj hauv qhov kev txiav txim siab
Synchronous Stress Management
Lub hardness ntawm beryllium tooj liab, armature, thiab kev sib cuag sib txawv heev. Peb cov thev naus laus zis tseem ceeb nyob hauv kev tswj cov yas rheology thaum lub sijhawm riveting, ua kom muaj kev ruaj ntseg xauv - nyob rau hauv lub armature yam tsis muaj kev cuam tshuam cov elastic modulus ntawm beryllium tooj liab.
Cov lus teb tsis tu ncua
Los ntawm kev tswj cov kev kam rau siab ntawm lub armature txheeb ze rau Beryllium Copper rau Hlau Stamping los ntawm precision pwm, peb xyuas kom meej lub torque tsis tu ncua rau electromagnetic quab yuam hloov dua siab tshiab, uas ua rau ib tug heev uniform relay kev koom tes thiab disengagement lub sij hawm.
Thermal Steady-Kev ua haujlwm hauv xeev
Vim lub cev nruj haum thiab diffusion cuam tshuam ntawm peb lub Cheebtsam, qhov kev pheej hmoo ntawm kev tsis zoo soldering raug tshem tawm. Thaum lub caij nplooj ntoos hlav loj dhau los, cov cua sov tuaj yeem ua tau sai los ntawm kev sib cuag mus rau lub caij nplooj ntoos hlav thiab tom qab ntawd diffused mus rau armature, txo qhov kub ntawm tag nrho cov khoom.
Daim ntawv thov qhov zoo: Cov xwm txheej ua tau zoo ntawm Relay thiab Hloov Caij Nplooj Ntoos Hlav
| Clamping Relay Caij Nplooj Ntoos Hlav | Hauv clamping electromagnetic relays, ib kawg ntawm Beryllium Copper Hlau Stampings sib dhos yog tsau rau tus quab, thaum lwm qhov kawg yog qhov kawg pub dawb rau kev sib cuag. Lub armature yog riveted mus rau nruab nrab seem ntawm lub caij nplooj ntoos hlav. Thaum lub coil yog energized, lub armature yog attracted rau cov tub ntxhais, thiab lub caij nplooj ntoos hlav khoov mus kaw rau pem hauv ntej kev sib cuag. Tom qab de-energization, lub elastic retoring quab yuam ntawm lub caij nplooj ntoos hlav thawb lub armature rov qab mus rau nws tus qub txoj hauj lwm. Lub siab qaug zog tsis kam ntawm beryllium tooj liab ua kom ntseeg tau tias lub rooj sib txoos tswj kev sib cuag ruaj khov thiab dhau mus txawm tias tom qab ntau lab lub voj voog. |
| Hloov Caij Nplooj Ntoos Hlav | Lub Beryllium Copper Stamping Part cov rooj sib txoos hauv phab ntsa hloov, microswitches, thiab kev txwv hloov pauv zoo ib yam li cov hauv relays, tab sis nrog cov qauv yooj yim. Cov keyboards feem ntau tsis muaj kev ywj pheej armature; lub caij nplooj ntoos hlav nws tus kheej yog ob qho tib si elastic caij thiab lub caij tsav tsheb, ncaj qha tsav los ntawm lub pob lossis lub zog. Cov nyiaj tiv tauj yog riveted mus rau qhov kawg ntawm lub caij nplooj ntoos hlav thiab cov phooj ywg nrog rau qhov chaw ruaj khov. Hloov cov springs muaj cov kev cai tshwj xeeb rau siab elasticity, tsis yog -magnetic zog, thiab corrosion kuj ntawm beryllium tooj liab. |
| Thermostat thiab Protector Spring Assembly | Beryllium Copper Stamping Techniques rau kev sib koom ua ke hauv qhov ntsuas kub yuav tsum tiv thaiv lub zog tsav los ntawm kev khoov ntawm cov kub bimetallic strip. Nws ua haujlwm dhau qhov kub ntawm qhov dav (-40℃txog 150 degree), yuav tsum muaj thermal stability ntawm cov ntaub ntawv. Beryllium tooj liab nthuav tawm qhov qis dua ntawm kev hloov pauv ntawm elastic modulus tshaj qhov kub ntau dua li phosphor bronze. Ua ke nrog AgSnO₂ lossis AgNi10 nyiaj tiv tauj, qhov no ua kom lub ntsuas sov ua haujlwm kub raug thiab lub neej hluav taws xob. |
Qhia kom ntxaws: Cov ntaub ntawv pov thawj zoo Engineering Cov neeg siv khoom yuav tsum tau them rau
Kev tshuaj xyuas metallographic
Saib xyuas cov nplej elongation lub xeev ntawm lub caij nplooj ntoos hlav khoov los txiav txim seb cov txheej txheem stamping ua rau microcracks lossis kev ntxhov siab concentration. Tus ntoo khaub lig- ntu ntawm thaj chaw tiv tauj riveting yuav tsum qhia tus Tsov tus tw tag nrho qhib rau hauv lub kaus zoo, nruj haum rau Beryllium Copper Sheet Hlau Stamping Parts rau Electronic lub qhov phab ntsa.
Thrust Test Data
Rau Beryllium Copper Strips rau Stamping Parts nrog lub taub hau ntawm lub taub hau ntawm 3 hli, lub axial thrust yuav tsum ntau dua los yog sib npaug rau 80N. Rau armature riveting txoj hauj lwm, lub thrust yuav tsum siab tshaj los yog sib npaug rau 120N. Hom tsis ua hauj lwm yuav tsum yog hlau tearing nyob rau hauv qhov chaw riveting es tsis slippage.
Tiv tauj ntsuas ntsuas
Ntsuas siv plaub- txoj kev xaim ntawm qhov tam sim no ntawm 1 ~ 10A. Qhov kev tiv thaiv thawj zaug yuav tsum tsawg dua lossis sib npaug ntawm 50μΩ, thiab qhov hloov pauv yuav tsum tsis pub tshaj ± 10% tom qab kev ntsuas lub neej.
Overtravel Consistency Test
Batch sampling tshuaj xyuas siv lub laser xaav sensor; qhov sib cuag qhov siab sib txawv yuav tsum tsawg dua los yog sib npaug rau 0.05mm.
tiv tauj peb
Yog tias koj tab tom nrhiav ib tus neeg muag khoom ntawm lub caij nplooj ntoos hlav riveting dynamic nrog kev ntseeg siab thiab kev sib koom tes ntawm engineering, peb tuaj yeem muab kev tsim kho kom zoo thiab tsim kev txhawb nqa raws li koj qhov kev tsim qauv, pab koj qhov project kom ua tau sai thiab ua haujlwm ruaj khov rau lub sijhawm ntev.Beryllium Copper Stamping Techniques rau Cheebtsam.
Cim npe nrov: Beryllium Sheet Stamping Terminals Chaw tsim tshuaj paus, lwm tus neeg, Hoobkas
